Description
The Klotz LY215S.A is a twinaxial speaker cable, designed to be an industry standard for connecting mobile speaker systems with long cable runs and large conductor areas or short bridge cables with lower power requirements. It features a very short length of core twist for improved EMC and is known for being extraordinarily flexible, making it ideal for winding on cable drums.
Specifications for Klotz LY215S.A: * Conductor: Stranded bare copper
* Insulation: Blue & red
* Core arrangement: 2 cores twisted to a pair
* Outer Jacket: PVC, matt, black
* No. of cores: 2
* Cond. Cross-Section: 1.5 mm2
* Cond. Construction: 30 x 0.25 mm
* Conductor Resistance: 12.5 Ω/km
* Capacitance: 150 pF/m
* Inductance: 0.56 µH/m
* Outer Diameter: 7 mm
* Max. Operating Voltage: 300 V
* Test Voltage [50 Hz, 1 min]: 2000 V
* Min. Bending Radius: 5 x overall diameter
* Working Temperature: -20 °C / +70 °C
