Description
The Klotz P0122YSW is a balanced single pair wiring cable, also referred to as a balanced signal cable. With an overall diameter of only 3.4 mm, it is suitable for rack wiring and studio cabling in applications without mechanical stress.
Specifications: * Conductor Cross Section: 0.22 mm² (AWG 24)
* Construction: Stranded tinned copper, 7 x 0.20 mm (AWG 24/7)
* Insulation: Polyethylene (PE)
* Drain Wire: Stranded tinned copper, 7 x 0.20 mm
* Shielding: AL/PET foil
* Overall Diameter: 3.4 mm
* Conductor Resistance: < 85 Ω/km
* Capacitance (Cond./Cond.): 85 pF/m
* Capacitance (Cond./Shield): 160 pF/m
* Insulation Resistance: > 10 GΩ x km
* Cable type: Balanced signal cable
