Description
The Neutrik NA2F-J-TX is a miniature transformer balancing adapter that converts unbalanced/balanced lines and is used for passive DI applications where no earth or gain switching is required. It features a 3-pole XLR female connector and a locking 1/4″ jack (6.35mm female) connector, with a ground lift option. It has a rugged aluminum extrusion housing for reliability and is part of the D shape adapters line. The audio transformer is 1:1, with an impedance ratio of 200:200, and a source/load impedance of 200/2k or (600/10k) Ohm.
Specifications: * Product Type: Audio Adapters/XLR Connectors
* Connector 1 type: 1/4″ TRS
* Connector 1 gender: Female connector
* Connector 2 type: XLR
* Connector 2 gender: Female connector
* Impedance ratio: 200:200
* Source/load impedance: 200/2k Ohm, (600/10k) Ohm
* Depth: 79.1 mm
* Height: 31 mm
* Width: 26 mm
* Housing material: Aluminum
* Product colour: Black
