Description
The Klotz CTV1/P is a professional-grade hybrid cable designed for CCTV systems, integrating one video coaxial cable and two power conductors in a parallel zip format. This configuration simplifies installation by allowing simultaneous video and power transmission over a single cable run.
The video cable features a stranded bare copper conductor with PE insulation and shielding for reliable composite video signal transmission. The power section includes two 0.75 mm² copper conductors suitable for DC power supply to surveillance cameras. The cable’s flat profile allows easy routing and separation if needed, and its PVC jacket ensures durability in fixed installations.
With outer dimensions of 12.0 mm x 5.8 mm and a weight of 0.08 kg/m, the CTV1/P is optimized for commercial CCTV setups requiring efficient cabling and minimal electromagnetic interference.
Specifications:
– Type: Hybrid CCTV cable (video + power)
– Construction: Parallel zip cord, splitable
– Video Cable: Stranded bare copper, PE insulated, shielded
– Power Cable: 2 x 0.75 mm² copper conductors
– Outer Dimensions: 12.0 mm x 5.8 mm
– Jacket: PVC
– Weight: 0.08 kg/m
– Application: Surveillance camera installations, fixed commercial setups
