Description
The Neutrik NL4FX-5 is a 4-pole Speakon cable connector designed for professional speaker and amplifier connections. It features a straight cable entry and is preassembled with a gray bushing to indicate 5 mm cable compatibility.
This connector supports high current transmission (up to 40 A RMS continuous) and includes Neutrik’s secure quick-lock system for reliable mating. The chuck-type strain relief ensures firm cable retention, and the screw-type terminals allow easy assembly without soldering. The NL4FX-5 is ideal for live sound, touring systems, and fixed installations.
Specifications:
– Type: 4-pole Speakon cable connector (straight)
– Cable Compatibility: 5 mm diameter (gray bushing)
– Rated Current: 40 A RMS continuous
– Rated Voltage: 250 V AC
– Locking: Quick-lock with secure latching
– Strain Relief: Chuck-type
– Termination: Screw-type terminals
– Application: Speaker cables, amplifier outputs, live sound systems
– Compliance: IEC 61984
